Texas Instruments Product - SN74LVC125ARGYR

The SN74LVC125ARGYR is an advanced quad bus buffer gate product from the globally renowned electronics company, Texas Instruments. This high-quality product features 3-state outputs that are designed to handle the bus line loads in both high-speed digital systems and low-power applications.

The device comes with four independent gates, each of which performs the Boolean function Y = A in positive logic. It is designed to have the capability to drive 50 Ω transmission lines. The 3-state control gate is a 2-input AND gate with active-low inputs so that if any one of the output-enable (OE) inputs is high, the outputs are in the high-impedance state. However, the SN74LVC125ARGYR does not have a series base resistor to the base drive circuit. This feature allows the device to sink or source 24 mA into the high-level output (IOH).

This product is available in a variety of packages including 14-pin SOIC, 14-pin TSSOP, 14-pin TVSOP, 14-pin VQFN, and 20-pin QFN. The SN74LVC125ARGYR operates over a wide voltage range from 1.65 V to 3.6 V, making it suitable for a wide range of applications. It has a maximum propagation delay of 4.7 ns, ensuring high-speed operation.

The SN74LVC125ARGYR is characterized for operation from -40°C to 85°C. It is also RoHS compliant and free from lead, bromine and antimony, making it an environmentally friendly choice. The product is designed for optimal performance, durability, and reliability, making it a popular choice among customers seeking high-quality buffer gate solutions.

For more information about SN74LVC125ARGYR and other Texas Instruments products, please visit the official Texas Instruments website.
