SN74LS04NSR Real Image SN74LS04NSR real image6019 SN74LS04NSR Real Image
Same model may have multiple batches, images only for reference.
SN74LS04NSR Real Image SN74LS04NSR real image6019 SN74LS04NSR Real Image
SN74LS04NSR Real Image SN74LS04NSR real image6019 SN74LS04NSR Real Image
Same model may have multiple batches, images only for reference.

SN74LS04NSR

Part No SN74LS04NSR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description Inverter 6-Element Bipolar 14-Pin SOP T/R / IC HEX INVERTER 14SO
Datasheet
SN74LS04NSR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Supply Voltage - Operating 4.75 V to 5.25 V
Current - Output High, Low 400μA, 8mA
Logic Level - Low 0.8V
Logic Level - High 2V
Max Propagation Delay @ V, Max CL 15ns @ 5V, 15pF
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SOP
Dimension 14-SOIC (0.209", 5.30mm Width)
Win Source Part Number 030167-SN74LS04NSR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SN74LS04
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian SN74LS04NSR CAD Model

Description

The SN74LS04NSR is a high-performance, advanced integrated circuit (IC) developed by the renowned manufacturer, Texas Instruments.

  • Device: Hex Inverter
  • Voltage Range: 4.75V to 5.25V
  • Nominal Voltage: 5V
  • Technology: Schottky-clamped circuitry
  • Typical Propagation Delay Time: 10ns
  • Package: Compact SOP-14 package
  • Operating Temperature Range: From 0°C to 70°C
  • Compliance: RoHS compliant
