Product Overview: SN74ACT573DWR from Texas Instruments

The SN74ACT573DWR is a high-performance, octal transparent D-type latch designed by Texas Instruments, renowned for its innovative semiconductor solutions. This integrated circuit is part of the 74ACT series, which is known for its high-speed CMOS logic operating with advanced AC-type circuitry. The device is specifically crafted to address the requirements of high-speed memory buffering and data storage applications.

Key Features

• Logic Type: Octal D-Type Transparent Latch with 3-state outputs.
• Package: The device comes in a wide-body SOIC package (suffix 'DW'), with 20 pins (referred to as 'DWR' for the tape and reel packaging option).
• Logic Level: Operates at TTL-compatible input voltage levels, ensuring easy interfacing with traditional TTL logic.
• Supply Voltage: Designed to operate within a supply voltage range of 4.5 V to 5.5 V, making it suitable for typical 5V logic systems.
• Output Capability: Capable of driving up to 24 mA at the output, allowing direct driving of a wide range of loads.
• Performance: Features fast propagation delays and reduced power consumption, enhancing overall system speed and efficiency.
• Temperature Range: The device is specified for operation from -40°C to 85°C, making it reliable for industrial temperature environments.

Applications

The SN74ACT573DWR is versatile and can be used in various applications, including:

• Memory data storage and retrieval systems
• Buffer registers for data management
• Communication systems
• Embedded processing
• Industrial control systems

Quality and Reliability

Texas Instruments is committed to delivering high-quality products. The SN74ACT573DWR is no exception, as it undergoes rigorous testing and validation to ensure it meets the industry standards for reliability and performance.

Ordering Information

The product is available in tape and reel packaging, facilitating automated assembly processes, and is denoted by the 'DWR' suffix at the end of the product code. For detailed ordering and shipping information, please refer to the Texas Instruments website or authorized distributors.
