The SN65HVD231QDRQ1 is a robust, high-performance Controller Area Network (CAN) transceiver from Texas Instruments designed to facilitate communication in automotive and industrial applications. This device provides the interface between a CAN protocol controller and the physical two-wire CAN bus, and is compliant with the ISO 11898-2 High Speed CAN physical layer standard.

Key Features

• Bus-Pin ESD Protection: With an impressive Electrostatic Discharge (ESD) protection exceeding 16 kV on the bus pins, the SN65HVD231QDRQ1 ensures reliability and robustness in harsh environments.
• Low Power Consumption: It features a very low current standby mode (typical 370 µA), which is essential for power-sensitive applications.
• Differential Output Exceeds 2 V: The device provides a differential output that exceeds 2 V with a 54-Ohm load, ensuring strong signaling in noisy environments.
• Thermal Shutdown Protection: The transceiver includes thermal shutdown protection that disables the transmitter in the event of excessive temperature, preventing damage to the device.

Applications

The SN65HVD231QDRQ1 is ideal for a variety of applications that require reliable data transmission, including:

• Automotive networks
• Industrial automation and control systems
• Medical equipment
• Building automation

Quality and Reliability

As a part of Texas Instruments' commitment to quality, the SN65HVD231QDRQ1 is designed to meet the stringent requirements of the automotive industry. It is qualified for use in automotive applications according to the AEC-Q100 standards, ensuring performance and reliability for the end user.

Package and Availability

The transceiver comes in a small, 8-pin SOIC package, and is available in tape and reel for use in automated manufacturing processes. Its part number SN65HVD231QDRQ1 reflects the package type and quality grade, with the 'Q' denoting the device's automotive qualification.
