Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Voltage - Clamping 7V
Technology Mixed Technology
Number of Circuits 1
Applications USB
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 042702-SN65220DBVT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Communications & Networking
Ultra Librarian 3D Model Ultra Librarian SN65220DBVT CAD Model

Description

The SN65220DBVT from Texas Instruments is a highly sophisticated and reliable electronic component that serves as a USB port transient suppressor.

  • Standards: IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT), and IEC 61000-4-5 (Surge)
  • Peak Pulse Power Rating: 500W for an 8/20μs waveform
  • Applications: USB port protection, digital camera interface protection, and protection of portable electronics
  • Package: 5-pin SOT-23
  • Features: Low clamping voltage and low capacitance
