REF3312AIDCKR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 1.25V
Output Current 30mA
Tolerance ±0.15%
Temperature Coefficient 30ppm/°C
Noise - 0.1Hz to 10Hz 35μVp-p
Voltage - Input 1.8 V to 5.5 V
Operating Supply Current 8.5μA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SC-70-3
Win Source Part Number 062450-REF3312AIDCKR
Popularity Medium
Supply and Demand Status Sufficient
Application Field Used in Portable Devices, Computers & Computer Peripherals, Sensing & Instrumentation, Medical, Test & Measurement
Ultra Librarian 3D Model Ultra Librarian REF3312AIDCKR CAD Model

Description

Product REF3312AIDCKR from Texas Instruments is a high-performance, low-power, precision voltage reference.

  • Output Voltage: 1.25V
  • Temperature Drift: 50ppm/°C (maximum) over temperature
  • Quiescent Current: 100µA (maximum) @ 25°C
  • Output Current: ±10mA
  • Operating Temperature Range: -40°C to +125°C
