PTH05000WAST

Part No PTH05000WAST
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description MODULE PIP 5VIN 6A ADJ SMD
Datasheet
PTH05000WAST Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series PTH05000W
Packaging Reel(TR)
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 0.9 ~ 3.6 V
Current - Output (Max) 6A
Applications ITE (Commercial)
Features OTP, UVLO
Mounting Style SMD/SMT
Package 5-SMD Module
Size / Dimension 0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 92%
Power (Watts) - Max 21.6W
Win Source Part Number 210338-PTH05000WAST
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PTH05000WAST CAD Model

Description

The PTH05000WAST is a highly sophisticated, high-performance, non-isolated power module from Texas Instruments, a leading global semiconductor company.

  • Rated Current: 6A
  • Adjustable Output Voltage Range: 0.8V to 3.6V
  • Efficiency: Up to 96%
  • Auto-Track Sequencing: Yes
  • Over-Temperature Protection: Yes
  • Under-Voltage Lockout Protection: Yes
  • On/Off Inhibit: Yes
  • Output Voltage Adjust (Trim): Yes
  • Output Current Monitor: Yes
