PT6303R Real Image
Same model may have multiple batches, images only for reference.

PT6303R

Part No PT6303R
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description 3 AMP ADJUSTABLE POSITIVE STEP-DOWN INTEGRATED SWITCHING REGULATORS
Datasheet
PT6303R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Pin Count 12
Operating Temperature (Max) 85C
Operating Temperature (Min) -40C
Screening Level Industrial
Rad Hardened No
Mounting Style Through Hole
Type Step Down
Number of Outputs 1
Package SIP Module
Product Length (mm) 59.94(mm)
Product Depth (mm) 9.4(mm)
Product Height (mm) 17.01(mm)
Input Voltage 9 to 26(V)
Output Current 3(A)
Output Voltage 3.3(V)
Isolation Non-Isolated
Win Source Part Number 062150-PT6303R
Popularity Medium
Supply and Demand Status Balance
Quantity per package 12
Ultra Librarian 3D Model Ultra Librarian PT6303R CAD Model

Description

The PT6303R is an innovative and high-quality product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Description: 3A, 5V input adjustable/positive output integrated switching regulator (ISR)
  • Efficiency: Up to 90% @ full load
  • Input Voltage Range: 4.5V to 11V
  • Output Voltage: Adjustable from 1.3V to 5.5V
  • Output Voltage Accuracy: ±2%
