OPA4180IDR Real Image OPA4180IDR Real Image1 OPA4180IDR Real Image2
Same model may have multiple batches, images only for reference.
OPA4180IDR Real Image OPA4180IDR Real Image1 OPA4180IDR Real Image2
OPA4180IDR Real Image OPA4180IDR Real Image1 OPA4180IDR Real Image2
Same model may have multiple batches, images only for reference.

OPA4180IDR

Part No OPA4180IDR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description Op Amp Quad Zero Drift Amplifier R-R O/P ±18V/36V 14-Pin SOIC T/R / IC OPAMP ZERO-DRIFT 2MHZ 14SOIC
Datasheet
OPA4180IDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type Zero-Drift
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 0.8 V/μs
Gain Bandwidth Product (GBP) 2MHz
Current - Input Bias 250pA
Voltage - Input Offset 15μV
Operating Supply Current 450μA
Channel Output Current 18mA
Supply Voltage - Operating 4 V to 36 V, ±2 V to 18 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 117956-OPA4180IDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name OPA4180
Introduction Date November 17, 2011
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian OPA4180IDR CAD Model

Description

The OPA4180IDR is a high-performance, ultra-low power, precision operational amplifier from Texas Instruments, a renowned global semiconductor company that designs and manufactures analog ICs and embedded processors.

  • Power Consumption: Ultra-low power consumption
  • Supply Range: 1.8 V to 5.5 V (single), ±0.9 V to ±2.75 V (dual)
  • Quiescent Current: 475 µA (typical) per amplifier @ 5 V
  • Offset Voltage: 150 µV (maximum)
  • Offset Drift: 0.5 µV/°C (maximum)
  • Input Bias Current: 20 pA (maximum)
  • Gain Bandwidth: 2 MHz
  • Slew Rate: 0.6 V/µs
  • Feature: Shutdown mode
  • Package: 14-pin TSSOP
  • Operating temperature: -40°C to +125°C
