Products specifications

Category Integrated Circuits (ICs)>Embedded>Microcontrollers
Manufacturer Texas Instruments
Packaging Reel - TR
Core Processor MSP430 CPU16
Core Size 16-Bit
Speed 24MHz
Connectivity I2C, IrDA, SPI, UART/USART
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O 44
Program Memory Size 16KB (16K x 8)
Program Memory Type FRAM
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V ~ 3.6V
Data Converters A/D 12x12b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 105°C
Mounting Surface Mount
Case / Package 48-LQFP
Supplier Device Package 48-LQFP (7x7)
Base Product Number MSP430FR2153
RoHS Status ROHS3 Compliant
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Other Part Number 296-MSP430FR2153TPDKR,MSP430FR2153TPTR-ND,296-MSP430FR2153TPTR,296-MSP430FR2153TPCT
Standard Package 1,000
Win Source Part Number 1318621-MSP430FR2153TPTR
Ultra Librarian 3D Model Ultra Librarian MSP430FR2153TPTR CAD Model

Description

The MSP430FR2153TPTR from Texas Instruments is a powerful and versatile microcontroller that is part of the MSP430 family, known for its ultra-low-power performance and integrated smart analog and digital peripherals. This specific model is designed to meet the needs of a wide range of embedded applications, particularly those that require efficient power management and reliable operation in constrained environments.

Key Features:

  • 16-Bit RISC Architecture: The MSP430 core is built on a 16-bit RISC architecture that delivers a balanced combination of performance and power efficiency, making it ideal for battery-powered and portable devices.
  • Low Power Consumption: This microcontroller features Texas Instruments' low-power ferroelectric RAM (FRAM), which not only provides faster write speeds and greater read/write endurance than traditional non-volatile memories but also significantly reduces power consumption during operation.
  • Integrated Peripherals: The MSP430FR2153TPTR comes with a diverse set of peripherals, including a 10-bit analog-to-digital converter (ADC), a 32-bit hardware multiplier, and multiple communication interfaces such as I2C, SPI, and UART, allowing for versatile connectivity and sensor integration.
  • Flexible Clock System: The device's flexible clock system supports multiple clock sources and allows for dynamic clock switching, which can be used to optimize performance and power consumption according to the application's needs.
  • Robust Security Features: Enhanced security measures are built-in, including a hardware multiplier for encryption and decryption tasks, and a watchdog timer to ensure system reliability.

Applications:

The MSP430FR2153TPTR is suitable for a wide array of applications, including but not limited to:

  • Wireless sensors and IoT devices
  • Energy harvesting systems
  • Portable medical devices
  • Home automation and smart metering
  • Industrial control systems

With its robust feature set and low-power operation, the MSP430FR2153TPTR from Texas Instruments is an excellent choice for designers who require a reliable microcontroller that can operate efficiently in power-sensitive applications.
