MAX3243EIRHBR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 3/5
Duplex Full
Receiver Hysteresis 500mV
Data Rate 500kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 32-VQFN (5x5)
Win Source Part Number 003049-MAX3243EIRHBR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3243EIRHBR CAD Model

Description

The MAX3243EIRHBR is a high-performance, robust product from Texas Instruments, a leading global semiconductor company.

  • Description: 3-V to 5.5-V Multichannel RS-232 Line Driver/Receiver with +/-15kV ESD Protection
  • Package: 28-pin QFN (Quad Flat No-Leads) package
  • Operating Temperature Range: -40°C to +85°C
  • Power Supply: Single power supply ranging from +3.0V to +5.5V
  • Feature: Automatic power-down function
  • ESD Protection: +/-15kV using the Human Body Model
  • Data Rates: Up to 250 kbps
  • Channels: Five drivers and three receivers
