MAX3232EIDW Real Image MAX3232EIDW Real Image1 MAX3232EIDW Real Image2
Same model may have multiple batches, images only for reference.
MAX3232EIDW Real Image MAX3232EIDW Real Image1 MAX3232EIDW Real Image2
MAX3232EIDW Real Image MAX3232EIDW Real Image1 MAX3232EIDW Real Image2
Same model may have multiple batches, images only for reference.

MAX3232EIDW

Part No MAX3232EIDW
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC RS232 3V5.5V 15KVESD 16-SOIC
Datasheet
MAX3232EIDW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 082987-MAX3232EIDW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX3232EIDW CAD Model

Description

The MAX3232EIDW from Texas Instruments is a high-quality, advanced dual driver/receiver that includes a capacitive voltage generator to supply RS-232 voltage levels from a single 3.0 to 5.5V supply.

  • Device Family: MAX3221E, MAX3232E, and MAX3241E
  • Pin Count: 16-pin
  • Data Signaling Rate: Up to 250 kbit/s
  • Drivers: 2
  • Receivers: 2
  • Drivers Protection: Short-circuit current limited, thermal shutdown circuitry
  • Standby Current: 1 μA (typical)
  • ESD Protection: Over ±15kV (Human Body Model)
  • Standards Compliance: TIA/EIA-232-F and ITU V.28
  • Environmental Compliance: RoHS
  • Package: SOIC (DW)
