Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 082986-MAX3232EID
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3232EID CAD Model

Description

The MAX3232EID is a high-quality, reliable, and efficient product from Texas Instruments, a leading global semiconductor company.

  • Device Type: Dual Driver/Receiver
  • Voltage Supply: Single 5-V
  • Receiver Input: TIA/EIA-232-F to 5-V TTL/CMOS Levels
  • Receiver Threshold: 1.3 V (typical)
  • Receiver Hysteresis: 0.5 V (typical)
  • Receiver Input Acceptance: ±30-V
  • Data Signaling Rate: Up to 250 kbit/s
  • Driver Output Slew Rate: Maximum 30-V/µs
  • Operating Temperature: 0°C to 70°C
  • ESD Protection (Human-Body Model): 2000-V (JESD 22, A114-A)
  • ESD Protection (Machine Model): 200-V (JESD 22, A115-A)
  • ESD Protection (Charged-Device Model): 1000-V (JESD 22, C101)
  • External Capacitors: 0.1 µF
  • Package: 16-pin SOIC
  • Compliance: RoHS Compliant
