Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 082983-MAX3232CDWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals, Portable Devices, Sensing & Instrumentation, Wireless, Industrial
Family Name MAX3232
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian MAX3232CDWR CAD Model

Description

The MAX3232CDWR from Texas Instruments is a high-quality, robust and reliable device that is designed to provide a seamless and efficient interface between RS-232 and low-voltage digital logic systems.

  • Operating Voltage: 3.0V to 5.5V
  • Features: Two receivers and two drivers
  • Data Signaling Rates: Up to 250 kbit/s
  • ESD Protection: Exceeds the requirements of the IEC 61000-4-2 standard for ESD protection
  • Package: Compact SOIC (DW) package
  • Feature: Automatic power-down function
  • Temperature Range: -40°C to 85°C
