Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 021499-MAX3232CDR
Family Name MAX3232
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Computers & Computer Peripherals, Portable Devices
Ultra Librarian 3D Model Ultra Librarian MAX3232CDR CAD Model

Description

The MAX3232CDR is a high-quality, high-performance product from Texas Instruments, a leading global semiconductor company.

  • Description: Dual driver/receiver with capacitive voltage generator
  • Drivers Data Rate: Up to 250 kbps
  • Receivers Input: Up to ±30-V input and 3-kΩ to 7-kΩ input impedance when in shutdown mode
  • Operating Voltage: Single 5-V power supply
  • Power Consumption: Low-power shutdown mode
  • ESD Protection: Meets the requirements of the IEC 61000-4-2 international standard for ESD protection
  • Package: Space-saving SOIC package
  • Compliance: RoHS compliant
