Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 500mV
Data Rate 500kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 20-SSOP
Win Source Part Number 082980-MAX3223EIDBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX3223E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian MAX3223EIDBR CAD Model

Description

The MAX3223EIDBR is a high-performance, advanced line transceiver from Texas Instruments, a global semiconductor design and manufacturing company.

  • Product: 3-V powered EIA/TIA-232 and V.28/V.24 communications interface
  • Low Power Requirements: Yes
  • Shutdown Mode: 1-microampere low-power
  • Voltage Range: 3.0 V to 5.5 V
  • Data Rate: Up to 250 kbps
  • ESD Protection: Exceeds 15 kV using the human-body model (HBM)
  • Receivers: 2 (remain active in shutdown mode)
  • Drivers: 2
  • Package: 28-pin SSOP (DB)
  • Temperature Range: -40°C to 85°C
