Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 500mV
Data Rate 120Kbps
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 021310-MAX202IDR
Family Name MAX202
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian MAX202IDR CAD Model

Description

Product MAX202IDR from Texas Instruments is a sophisticated piece of equipment designed to ensure effective and efficient communication within electronic devices.

  • Type: dual driver/receiver
  • Feature: includes a capacitive voltage generator to supply TIA/EIA-232-F voltage levels from a single 5-V supply. Each receiver converts TIA/EIA-232-F inputs to 5-V TTL/CMOS levels. These receivers have a typical threshold of 1.3 V, a typical hysteresis of 0.5 V, and can accept ±30-V inputs. Each driver converts TTL/CMOS input levels into TIA/EIA-232-F levels.
  • Characterized operation: characterized for operation from 0°C to 70°C. The MAX232C is characterized for operation from 0°C to 70°C. The MAX232I is characterized for operation from -40°C to 85°C.
  • Family: MAX232 family from Texas Instruments.
  • Package: 16-pin SOIC package
  • Power consumption: low power consumption.
  • Data rate: high data rate.
  • Feature: has electrostatic discharge (ESD) protection for its RS-232 bus pins.
