The Texas Instruments LMK04816BISQX/NOPB is a high-performance, low-noise clock jitter cleaner and clock generator designed to meet the stringent requirements of communication, data acquisition, and industrial systems. This device is part of TI's clocking solutions that provide a flexible and robust method to distribute clocks across a system while reducing noise and jitter to improve signal integrity.

Key Features

• Integrated Voltage Controlled Oscillator (VCO): The LMK04816BISQX/NOPB includes an integrated VCO with a frequency range of 2.37 GHz to 2.63 GHz, providing a stable and precise clock source.
• Dual PLL Design: The device features a dual Phase-Locked Loop (PLL) architecture, which allows for better noise isolation and improved jitter performance.
• Low Noise Jitter Cleaner: With its advanced noise cleaning capabilities, the LMK04816BISQX/NOPB significantly reduces clock jitter, ensuring high-quality signal timing for sensitive applications.
• Flexible Output Clocks: It offers up to 14 configurable output clocks, enabling it to support a variety of clocking configurations and signal types.
• Programmable via SPI: The device can be programmed through a Serial Peripheral Interface (SPI), allowing for dynamic control and on-the-fly adjustments.
• Power Supply Range: The LMK04816BISQX/NOPB operates over a wide power supply range of 3.15 V to 3.45 V, accommodating various system power rails.

Applications

The LMK04816BISQX/NOPB is suitable for a range of applications, including but not limited to:

• Wireless infrastructure (base stations, backhaul)
• Networking equipment (routers, switches, servers)
• Test and measurement systems
• Data acquisition systems
• Medical imaging and diagnostics

Quality and Reliability

As a product of Texas Instruments, the LMK04816BISQX/NOPB is manufactured with a commitment to quality and reliability. The device is available in a 48-pin WQFN package and is specified for operation over the industrial temperature range of -40°C to 85°C. Its NOPB (No Lead (Pb)) designation indicates that it is designed for eco-friendly applications and complies with RoHS standards.
