XR2206D-F Exar Corporation XR2206D-F Real Image XR2206D-F real image XR2206D-F Real Image
Same model may have multiple batches, images only for reference.
XR2206D-F Exar Corporation XR2206D-F Real Image XR2206D-F real image XR2206D-F Real Image
XR2206D-F Exar Corporation XR2206D-F Real Image XR2206D-F real image XR2206D-F Real Image
Same model may have multiple batches, images only for reference.

XR2206D-F

Part No XR2206D-F
Manufacturer Exar Corporation
Catalog Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description Clock Generator 0.5MHz to 1MHz-IN 16-Pin SOIC W / Evaluation System User Manual | IC FUNCTION GENERATOR 16SOIC
Datasheet
XR2206D-F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer MaxLinear, Inc.
Packaging Tube
Status Obsolete
Type Function Generator
PLL No
Input TTL
Output TTL
Frequency - Max 1MHz
Divider/Multiplier Yes/Yes
Supply Voltage (V) 10V ~ 26V
Temperature Range - Operating 0°C ~ 70°C
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SOIC
Manufacturer Pack Quantity 47
MSL Level 3 (168 Hours)
Win Source Part Number 717076-XR2206D-F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name XR2206
Introduction Date June 01, 1997
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian XR2206D-F CAD Model

Description

The MaxLinear XR2206D-F is a function generator integrated circuit that is widely used in electronic test equipment, audio signal generators, and other applications that require precise waveform generation.

  • Package: 16-SOIC package.
  • Maximum Frequency: 1 megahertz.
  • Status: Obsolete product.
  • Popularity: Still popular in the market due to its high quality and performance.
  • Alternative Parts: Available as a replacement.
  • Supply and Demand Status: Limited.
  • Manufacturer Pack Quantity: 47.
