Product Overview: LM4859SPX/NOPB

The LM4859SPX/NOPB is a highly integrated audio amplifier solution from Texas Instruments, designed to provide a superior audio experience for a wide range of applications. This advanced audio IC combines a 1.1W mono bridge-tied load (BTL) amplifier and a 300mW stereo headphone amplifier into one compact package, making it an ideal choice for mobile phones, PDAs, laptops, and other portable devices where space is at a premium.

Key Features

• Output Power: The device is capable of delivering 1.1W of continuous average power to an 8Ω BTL load with less than 1% distortion (THD+N) from a 5V DC power supply, and 300mW per channel into 16Ω stereo headphones.
• Boomer Audio Power Amplifier: As part of TI's Boomer® product line, the LM4859 is designed specifically for high-quality audio applications requiring low voltage and minimal battery drain.
• Advanced Switching: The LM4859 can automatically switch between mono and stereo modes, as well as between headphone and speaker drive, making it extremely versatile for different audio output scenarios.
• Micro-Power Shutdown Mode: Featuring a micro-power shutdown mode with an exceptionally low shutdown current of 0.1µA, this amplifier is optimized for power-sensitive applications.
• Thermal and Short-Circuit Protection: The device includes built-in thermal shutdown and short-circuit protection features, ensuring reliable operation under various conditions.

Applications

The LM4859SPX/NOPB is suitable for a variety of audio applications, including:

• Portable electronic devices
• Mobile phones and smartphones
• Personal Digital Assistants (PDAs)
• Notebook and desktop computers
• Portable media players

Quality and Reliability

Encased in a 24-bump micro SMD package, the LM4859SPX/NOPB is designed for easy integration into system designs. This product is RoHS compliant and is manufactured to Texas Instruments' high standards for quality and reliability, ensuring performance in even the most demanding applications.

With its powerful output, low-voltage operation, and compact form factor, the LM4859SPX/NOPB from Texas Instruments is an excellent choice for designers looking to enhance the audio capabilities of their next-generation portable devices.
