LM393P Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Texas Instruments
Standard Package 50
Category Integrated Circuits(ICs)
Family Linear - Comparators
Packaging Tube
Type Differential
Number of Elements 2
Output Type CMOS MOS Open-Collector TTL
Voltage - Supply Single/Dual (±) 2 V ~ 36 V ±1 V ~ 18 V
Voltage - Input Offset (Max) 5mV @ 30V
Current - Input Bias (Max) 0.25µA @ 5V
Current - Output (Typ) 20mA
Current - Quiescent (Max) 2.5mA
Operating Temperature Range 0°C ~ 70°C
Package 8-DIP (0.300" 7.62mm)
Mounting Style Through Hole
Manufacturer Device Package 8-PDIP
Win Source Part Number 082754-LM393P
Family Name LM393
Introduction Date June 01, 2010
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Sensing & Instrumentation, Consumer Electronics, Portable Devices, Motor Drive & Control
Ultra Librarian 3D Model Ultra Librarian LM393P CAD Model

Description

The LM393P from Texas Instruments is an industry-leading, high-performance comparator that offers a comprehensive solution for a wide array of applications.

  • Type: Dual differential comparator
  • Supply Voltage: 2 to 36 volts
  • Current Drain: Low
  • Power Supply: Single or split
  • Differential Input Voltage Range: Equal to the power supply voltage
  • Input Offset Voltage: 2mV
  • Input Offset Current: 5nA
  • Operating Temperature Range: 0 to 70 degrees Celsius
  • Electrostatic Discharge Resistance: Designed to be resistant
  • Applications: Level detectors, alarm systems, voltage comparators, and general signal processing applications
  • Package: 8-pin PDIP
