ISO7421FED Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Bulk
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 1/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 50Mbps
Propagation Delay tpLH / tpHL (Max) 11ns, 11ns
Pulse Width Distortion (Max) 3.7ns
Rise and Fall Time 1.8ns, 1.7ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002080-ISO7421FED
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISO7421FED CAD Model

Description

The ISO7421FED is a high-performance, dual-channel digital isolator product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Supply Voltage Range: 3.0 to 5.5V
  • Data Rate: Up to 1 Mbps
  • Channels: Two isolated channels (one from side one to side two, and the other from side two to side one)
  • Isolation Voltage: 2500 Vrms for 1 minute per UL1577
  • Electromagnetic Compatibility (EMC): Excellent
  • Package: Compact 8-pin SOIC package
  • Operating Temperature Range: -40°C to +125°C
