ISO7241CDWR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 3/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002067-ISO7241CDWR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISO7241CDWR CAD Model

Description

The ISO7241CDWR is a high-performance, cutting-edge product from Texas Instruments, a multinational semiconductor technology company renowned for its innovative solutions.

  • Channels: Four independent isolation channels
  • Isolation Voltage: 2500 Vrms for 1 minute per UL and 4242 Vpk per VDE
  • Data Rate: Up to 25 Mbps
  • Fail-Safe Output: Yes
  • Temperature Range: -40°C to 125°C
  • Power Consumption: Low, consuming only 1.5 mA per channel @ 1 Mbps
  • Noise-Filtering Technology: Yes
  • Package: Compact, surface-mount SOIC package
