ADUM1401WSRWZ Digital Isolator by Analog Devices Inc.

The ADUM1401WSRWZ is a state-of-the-art digital isolator designed and manufactured by Analog Devices Inc., a leader in high-performance semiconductors. This product is built using Analog Devices' proprietary iCoupler® technology, which employs magnetic induction to provide galvanic isolation between input and output channels.

Key Features

• Channels: 4 Channels of isolation
• Isolation Voltage: 2500 V RMS for 1 minute
• Data Rate: Up to 10 Mbps
• Propagation Delay: Typically 13 ns
• Supply Voltage: Operates with a 3.0 V to 5.5 V supply voltage
• Package: 16-SOIC Wide Body (SOIC_W)
• Temperature Range: -40°C to +105°C
• Regulatory Approvals: UL, CSA, IEC, and VDE certifications

Applications

The ADUM1401WSRWZ is ideal for use in a variety of applications where data isolation is critical. These include:

• Industrial automation
• PLC (Programmable Logic Controllers)
• DCS (Distributed Control Systems)
• Data acquisition systems
• Test and measurement equipment
• Medical equipment with patient isolation

Product Advantages

With its robust design, the ADUM1401WSRWZ offers several advantages over traditional optocoupler-based isolators. The iCoupler technology ensures lower power consumption, improved data integrity, and a more reliable performance over a wide temperature range. The small footprint of the 16-SOIC package makes it suitable for space-constrained applications without compromising on isolation or performance.

Additional Information

For designers and engineers looking to integrate the ADUM1401WSRWZ into their systems, detailed technical documentation, application notes, and reference designs are available on the Analog Devices website. The product is also supported by Analog Devices' world-class technical support team, ensuring smooth integration and troubleshooting assistance when needed.
