ISO7221ADR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 1/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 1Mbps
Propagation Delay tpLH / tpHL (Max) 475ns, 475ns
Pulse Width Distortion (Max) 14ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002046-ISO7221ADR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Automation & Process Control, Sensing & Instrumentation, Industrial
Family Name ISO7221A
Introduction Date April 01, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian ISO7221ADR CAD Model

Description

The ISO7221ADR is a high-performance, digital isolator product manufactured by Texas Instruments, a renowned American technology company that designs and manufactures semiconductors and various integrated circuits.

  • Channels: Dual-channel
  • Data Rate: Up to 1 Mbps
  • Galvanic Isolation: Up to 2500 Vrms for 1 minute per UL and 4242 VPK per VDE
  • Supply Range: 3.0V to 5.5V
  • Operating Temperature Range: -40°C to +125°C
  • Power Consumption: 1.7 mA per channel @ 1 Mbps
  • Package: Compact 8-pin SOIC
