The INA196AIDBVT is a high-quality current shunt monitor from Texas Instruments, designed to provide precise and reliable current measurements in a wide range of applications. This device is part of the industry-leading INA19x series and is engineered to measure voltage drops across shunt resistors over a wide common-mode range from -16V to +80V, independent of the supply voltage.

Key Features

• High Common-Mode Range: The INA196AIDBVT is capable of measuring differential voltage signals on common-mode voltages from -16V to +80V, making it suitable for high-side current sensing in many applications.
• Wide Supply Range: This device operates on a supply range of 2.7V to 18V, providing flexibility in various power environments.
• Low Quiescent Current: With a quiescent current of only 100µA (typical), the INA196AIDBVT is an energy-efficient choice for battery-powered or energy-sensitive systems.
• High Accuracy: The INA196AIDBVT offers an accuracy of 1% (max) over the entire temperature range, ensuring precise current measurements for critical applications.
• Small Footprint: Housed in a compact SOT-23 package, this device is ideal for space-constrained applications.

Applications

The INA196AIDBVT is versatile and can be used in various applications, including:

• Automotive battery management systems
• Power management in telecommunication and industrial systems
• Overcurrent protection circuits
• Portable devices
• Test equipment and instrumentation

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the INA196AIDBVT is no exception. It is built to the highest standards, ensuring both robustness and performance for the most demanding environments. Whether you're designing for the automotive sector, industrial applications, or consumer electronics, the INA196AIDBVT provides a reliable solution for current sensing needs.

Ordering Information

The INA196AIDBVT is available for ordering in various quantities and packaging options to suit production scale requirements. For detailed ordering and pricing information, please contact Texas Instruments or an authorized distributor.
