Products specifications

Category Integrated Circuits (ICs)>PMIC - Motor Drivers, Controllers
Mfr Texas Instruments
Package Tube
Motor Type - Stepper Bipolar
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (4)
Interface Logic
Technology Power MOSFET
Step Resolution 1 ~ 1/16
Applications General Purpose
Current - Output 1.4A
Voltage - Supply 8V ~ 37V
Voltage - Load 8V ~ 37V
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting SMD (SMT)
Package / Case 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package 24-HTSSOP
Base Product Number DRV8886
Other Names DRV8886ATPWP,296-46556-5
Standard Package 60
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1253319-DRV8886ATPWP
Ultra Librarian 3D Model Ultra Librarian DRV8886ATPWP CAD Model

Description

Product Overview: DRV8886ATPWP from Texas Instruments

The DRV8886ATPWP is a highly-integrated motor driver from Texas Instruments (TI), designed to efficiently drive bipolar stepper motors or brushed DC motors. This advanced motor driver is a part of TI's extensive portfolio of motor control solutions and is engineered to offer a blend of power, precision, and ease of use for a wide range of applications.

Key Features

  • Integrated H-Bridge: The DRV8886ATPWP features a dual H-bridge motor driver, capable of driving two DC motors or one stepper motor. The H-bridge supports up to 1.5 A continuous drive current with up to 2.5 A peak current, making it suitable for a variety of medium-power applications.
  • Advanced Current Regulation: This product incorporates an advanced current regulation system that reduces the need for external components. It provides an adjustable current control to optimize motor performance and efficiency.
  • Microstepping Support: For stepper motors, the DRV8886ATPWP supports up to 1/16 microstepping, allowing for smoother and more precise motor movements, which is especially beneficial in applications requiring fine positioning.
  • Protection Features: The device includes multiple protection features such as overcurrent, thermal shutdown, and under-voltage lockout, enhancing system reliability and safety.
  • Power Supply Range: It operates over a wide power supply range from 4.5 V to 38 V, providing flexibility in various application scenarios and compatibility with different system voltages.

Applications

The DRV8886ATPWP is ideal for a diverse range of applications where precise motor control is required. Typical applications include:

  • Printers and office automation equipment
  • Textile and sewing machines
  • Robotics and factory automation
  • Consumer electronics

Package and Quality

Encased in a thermally efficient HTSSOP package, the DRV8886ATPWP is designed for optimal heat dissipation, ensuring reliable performance even under high-load conditions. TI's commitment to quality means that this motor driver is manufactured to the highest standards, ensuring consistent performance and long-term reliability for your projects.

Overall, the DRV8886ATPWP from Texas Instruments is a robust and versatile solution for designers looking to add reliable motor control to their embedded systems or industrial applications.
