Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology DMOS
Applications General Purpose
Output Current 2.8A
Supply Voltage - Operating 8 V to 38 V
Voltage - Load 8 V to 38 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 16-HTSSOP
Win Source Part Number 014626-DRV8801PWPR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name DRV8801
Introduction Date July 01, 2008
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian DRV8801PWPR CAD Model

Description

DRV8801PWPR Motor Driver IC

The DRV8801PWPR is an advanced motor driver IC optimized for high-performance applications. It is designed to drive a single brushed DC motor efficiently.

Features and Benefits

  • Flexible Voltage Operation: Compatible with power supplies from 8 V to 36 V.
  • Current Delivery: Capable of delivering continuous current of up to 2.8 A.
  • Comprehensive Protection: Features overcurrent, thermal, and undervoltage protections for safe operation.
  • Compact Size: TSSOP 20-pin PowerPAD package for efficient thermal management and compact design.

Applications

  • Automated Machinery
  • Medical Devices
  • Fitness and Wellbeing Equipment
  • Consumer Robotics
