Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Texas Instruments
Series SpeedPlus
Number of Converters 1
Resolution 8
Sampling Rate 60M
Data Interface Parallel
Input Range 2 Vpp
Power (Typ) @ Conditions 185mW @ 60MSPS
Utilized IC / Part ADS830E
Supplied Contents Board(s)
Win Source Part Number 768146-DEM-ADS830E
Popularity Medium
Supply and Demand Status Limited
Family Name DEM-ADS830E
Introduction Date September 01, 2001
ECCN EAR99
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian DEM-ADS830E CAD Model

Description

The DEM-ADS830E from Texas Instruments is a high-performance, 8-bit analog-to-digital converter (ADC) evaluation module designed for capturing high-speed signals with utmost precision. This device is a testament to Texas Instruments' commitment to providing advanced solutions for digital signal processing and data acquisition systems.

Key Features

  • High-Speed Performance: With a sampling rate of up to 60 MSPS (million samples per second), the DEM-ADS830E ensures that rapid signal variations are accurately captured, making it ideal for applications requiring high-speed data conversion.
  • Excellent Signal-to-Noise Ratio (SNR): This ADC features an impressive SNR, which provides a clear and precise digital representation of the analog input signal, minimizing the noise and enhancing signal fidelity.
  • Flexible Input Range: The device supports a wide input range, accommodating various signal amplitudes. This flexibility allows users to adapt the ADC to different signal sources without the need for external scaling components.
  • Easy Integration: The DEM-ADS830E comes in a user-friendly evaluation module format, simplifying the process of integrating the ADC into existing systems. It allows for quick prototyping and testing, accelerating the development cycle.
  • Robust Support Tools: Texas Instruments provides comprehensive support for the DEM-ADS830E, including detailed datasheets, application notes, and reference designs. This wealth of resources ensures that designers can fully leverage the ADC's capabilities.

Applications

The DEM-ADS830E is versatile and can be employed in a variety of applications where high-speed and accurate analog-to-digital conversion is paramount. These applications include but are not limited to:

  • Wireless communication systems
  • Test and measurement equipment
  • Medical imaging devices
  • Radar and satellite communication systems
  • High-speed data acquisition

With its exceptional performance and comprehensive support, the Texas Instruments DEM-ADS830E ADC is an ideal choice for engineers and designers looking to push the boundaries of high-speed digital conversion.
