Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Logic Type Astable, Monostable
Independent Circuits 1
Schmitt Trigger Input No
Propagation Delay 80ns
Current - Output High, Low 6.8mA, 6.8mA
Supply Voltage - Operating 3 V to 18 V
Temperature Range - Operating -55°C to 125°C
Mounting Through Hole
Case / Package 14-PDIP
Win Source Part Number 006178-CD4047BE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Clock & Timing
Ultra Librarian 3D Model Ultra Librarian CD4047BE CAD Model

Description

Description

The CD4047BE is a monostable/astable multivibrator chip providing precise control in electronic circuit timing. Its broad voltage compatibility and efficiency make it a preferred choice for reliable pulse generation applications.

Features and Benefits

  • Reliable monostable and astable performance for varied applications.
  • Power-efficient CMOS design, vital for low-power applications.
  • Flexible voltage range for integration in multiple circuit designs.
  • TTL compatibility that simplifies integration with diverse components and systems.

Applications

  • Automation timing control systems.
  • Signal processing and waveform shaping.
  • Timer circuits for consumer electronics.
  • Synchronous pulse production in industrial electronics.
