Product Overview: Texas Instruments CD4044BPWR

The Texas Instruments CD4044BPWR is a high-quality CMOS Quad NAND R/S Latch with 3-state outputs that is part of the renowned 4000 series logic integrated circuits. This device is designed to provide optimal performance in a wide variety of digital applications, including signal processing, data storage, and logic control systems.

Key Features

• Device Type: CMOS Quad NAND R/S Latch
• Output Type: 3-State
• Package / Case: TSSOP-16
• Mounting Type: Surface Mount
• Operating Temperature: -55°C to +125°C
• Supply Voltage Range: 3V to 18V
• Logic Family: CD4000
• Logic Type: Latch
• Number of Circuits: 4
• Independent Circuits: Yes

Product Description

The CD4044BPWR is a versatile and robust component that features four independent NAND R/S latches with three-state outputs. Each latch has its own set and reset inputs with the outputs capable of sinking or sourcing current up to 6.8mA. This makes the device highly suitable for interfacing with bus lines in a bus-organized system without the need for pull-up resistors.

Its wide supply voltage range from 3V to 18V allows the CD4044BPWR to be used in various applications, from low-voltage portable equipment to high-voltage logic systems. The device's inputs are protected against static discharge, ensuring reliability and longevity in the most demanding environments.

The TSSOP-16 package of the CD4044BPWR is designed for space-saving on PCBs, making it an excellent choice for compact electronic assemblies. Its surface-mount configuration facilitates efficient assembly processes and integration into automated manufacturing workflows.

With its extended operating temperature range of -55°C to +125°C, the CD4044BPWR from Texas Instruments is suitable for use in a wide range of industrial and commercial applications where temperature extremes are a concern. The combination of its durable design, high functionality, and compatibility with other logic families makes it a valuable component for designers looking to create reliable and efficient digital systems.

Overall, the CD4044BPWR is a testament to Texas Instruments' commitment to providing high-quality, reliable components for the electronics industry.
