BQ2022ADBZR Real Image BQ2022ADBZR Real Image
Same model may have multiple batches, images only for reference.
BQ2022ADBZR Real Image BQ2022ADBZR Real Image
BQ2022ADBZR Real Image BQ2022ADBZR Real Image
Same model may have multiple batches, images only for reference.

BQ2022ADBZR

Part No BQ2022ADBZR
Manufacturer Texas Instruments
Catalog Unclassified Memory
Description IC OTP 1KBIT SDQ SOT23-3
Datasheet
BQ2022ADBZR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Memory Format EPROM
Technology EPROM - OTP
Memory Size 1Kb (256b x 4 pages)
Supply Voltage - Operating 2.65 V to 5.5 V
Temperature Range - Operating -20°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 011851-BQ2022ADBZR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BQ2022ADBZR CAD Model

Description

BQ2022ADBZR 1-Wire Battery Fuel Gauge

The BQ2022ADBZR is a 1-wire battery fuel gauge designed for applications that require ultralow power consumption and reliable battery monitoring. This IC is especially suitable for compact, portable devices needing extended battery life.

  • Applications and Projects:
    • Smart health monitoring devices
    • Portable wireless sensors
    • Battery-powered medical equipment
    • Backup power systems
  • Features and Benefits:
    • Ultralow power operation
    • Simple 1-wire communication protocol
    • Integrated temperature sensor
    • Small footprint for space-constrained designs
  • Additional Details:
    • Operating voltage: 2.7V to 5.5V
    • Temperature range: -40°C to 85°C
    • Offered in an 8-pin SON package
