RB6122-36-0M5 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

RB6122-36-0M5

Part No RB6122-36-0M5
Manufacturer TE Connectivity
Catalog Common Mode Chokes
Description CMC 450UH 36A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 450 µH @ 1 kHz
Current Rating (Max) 36A
DC Resistance (DCR) (Max) 1.5mOhm (Typ)
Voltage Rating - DC 1000V (1kV)
Voltage Rating - AC 600V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Size / Dimension 2.402" L x 2.276" W (61.00mm x 57.80mm)
Height (Max) 1.496" (38.00mm)
Case / Package Horizontal, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530563-RB6122-36-0M5
Ultra Librarian 3D Model Ultra Librarian RB6122-36-0M5 CAD Model

Description

N

You May Also Be Interested in

ACM 3225F2DV-220T02-D Real Image1
ACM 3225F2DV-220T02-D
TAI-TECH Advanced Electronics
22 UH @ 100 KHZ 2 LINE COMMON MO / 22 µH @ 100 kHz 2 Line Common Mode Choke Surface Mount 1.1 kOhms @ 10 MHz 250mA DCR 500mOhm
Need more? Email Us
Picture of B1116
