Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Connector Type Plug
Contact Type Male or Female
Number of Positions 12
Pitch 0.198" (5.03mm)
Number of Rows 3
Row Spacing 0.198" (5.03mm)
Mounting Type Panel Mount, Snap-In
Contact Termination Crimp
Fastening Type Detent Lock
Color Natural
Insulation Material Polyamide (PA), Nylon
Temperature Range - Operating -55°C ~ 105°C
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1632948-770101-1
Ultra Librarian 3D Model Ultra Librarian 770101-1 CAD Model
