7-1393211-4 Real Image
Same model may have multiple batches, images only for reference.

7-1393211-4

Part No 7-1393211-4
Manufacturer TE Connectivity
Catalog Signal Relays, Up to 2 Amps
Description 30A 350Ohm 2 form A Panel Mount General Purpose Industrial Relay
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Coil Current 70.8 mA
Coil Power 1.5 W
Coil Resistance 350 Ω
Coil Type Non-Latching
Coil Voltage (DC) 24 V
Contact Current Rating 30 A
Contact Material Cadmium, Silver
Contact Voltage Rating (AC) 277 V
Height 26.3906 mm
Length 52.0954 mm
Maximum Operating Temperature 85 °C
Max Voltage Rating (AC) 600 V
Min Operating Temperature -55 °C
Mount Panel
Number of Pins 8
Operate Time 15 ms
Packaging Bulk
Relay Type General Purpose
Release Time 15 ms
RoHS Compliant
Termination Quick Connect
Throw Configuration DPST
Weight 86.012453 g
Width 34.5 mm
Win Source Part Number 960008-7-1393211-4
Categories Signal Relays,Up to 2 Amps
Manufacturer TE Connectivity
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 7-1393211-4 CAD Model

Description

The TE Connectivity 960008-7-1393211-4 general-purpose signal relay is a DPST (Double Pole Single Throw) relay with a contact current rating of 30 A and a contact voltage rating of 277 V AC.

  • Contact Current Rating: 30 A
  • Contact Voltage Rating: 277 V AC
  • Coil Voltage: 24 V DC
  • Coil Resistance: 350 Ω
  • Operate Time: 15 ms
  • Release Time: 15 ms
  • Mounting: Panel
  • Termination: Quick Connect
  • Dimensions: 52.0954 mm x 34.5 mm x 26.3906 mm
  • Weight: 86.012453 g
  • Maximum Operating Temperature: 85°C
  • Minimum Operating Temperature: -55°C
