Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Terminal Type Circular
Stud/Tab Size 8 Stud
Thickness 0.027" (0.69mm)
Width - Outer Edges 0.281" (7.14mm)
Length - Overall 0.814" (20.68mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp
Wire Gauge 24 AWG
Insulation Insulated
Features Insulation Restriction, Serrated Termination
Color Yellow, Blue Stripe
Contact Material Copper
Contact Finish Tin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1636131-53056
Ultra Librarian 3D Model Ultra Librarian 53056 CAD Model
