STGF19NC60KD - IGBT from STMicroelectronics

The STGF19NC60KD is a high-performance IGBT (Insulated Gate Bipolar Transistor) designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This IGBT is tailored for a wide range of power applications, particularly those requiring high-speed switching, low conduction losses, and robust thermal performance. It is well-suited for applications such as motor drives, uninterruptible power supplies (UPS), inverter circuits, and general-purpose power amplification and switching.

Key Features

• High Speed Switching: The device is capable of fast switching speeds, which makes it ideal for applications where efficiency and high-frequency operation are critical.
• Low Saturation Voltage: With a low on-state voltage drop, the STGF19NC60KD ensures reduced conduction losses, contributing to the overall efficiency of the system it is used in.
• High Current Rating: The IGBT has a high current carrying capacity, making it suitable for high power applications.
• Robust Thermal Performance: The device is designed to handle significant thermal stress, ensuring reliability and longevity even under high temperature operating conditions.
• Co-Packaged Diode: This IGBT comes with a free-wheeling diode co-packaged with the transistor. This feature simplifies the design and enhances the performance of the overall circuit by providing efficient reverse recovery characteristics.

Electrical Characteristics

At the core of the STGF19NC60KD's electrical characteristics is its 600V collector-emitter breakdown voltage, which provides a generous margin for high-voltage applications. The device also boasts a low collector-emitter saturation voltage of typically 2.1V, which minimizes power dissipation during conduction. Its maximum continuous collector current at room temperature is 19A, with a pulsed collector current capability of 76A, allowing for transient high-power operation.

Package and Reliability

The STGF19NC60KD comes in a TO-220 FullPAK package, which provides excellent isolation between the semiconductor and the heatsink. This package is widely used for its ease of mounting and reliable thermal and electrical performance. STMicroelectronics also ensures that this IGBT meets stringent reliability standards, offering a robust solution for designers looking to incorporate a dependable power transistor into their applications.
