20EP6 Real Image
Same model may have multiple batches, images only for reference.

20EP6

Part No 20EP6
Manufacturer TE Connectivity
Catalog Power Line Filter Modules
Description LINE FILTER 250VAC 20A CHASS MNT  /  Single Phase EMC/EMI Line Filter 20 A 250VAC 50/60Hz Two Stage Threaded Post (8-32)
Datasheet
20EP6 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Power Line Filter Modules
Mfr TE Connectivity Corcom Filters
Series EP
Package Bulk
Filter Type Single Phase
Configuration Two Stage
Voltage - Rated AC 250V
Current 20 A
Frequency - Operating 50/60Hz
Applications General Purpose
Approval Agency CSA, UR, VDE
Temperature Range - Operating -10°C ~ 40°C
Mounting Type Chassis Mount
Termination Style Threaded Post (8-32)
MSL Level Not Applicable
REACH Status REACH Affected
ECCN EAR99
HTSUS 8548.00.0000
Other Names 20EP6-ND,CCM1827,20EP6-NDR,1-6609037-0,1-1609037-0,-20EP6-SI
Standard Package 8
Win Source Part Number 1036372-20EP6
Ultra Librarian 3D Model Ultra Librarian 20EP6 CAD Model

Description

The TE Connectivity Corcom Filters EP series power line filter module is a two-stage filter designed for use in general-purpose applications.

  • Series: EP
  • Filter Type: Power Line Filter Module
  • Number of Stages: Two-Stage
  • Current Rating: 20A
  • Rated Voltage: 250V AC
  • Frequency Range: 50/60Hz
  • Temperature Range: -10°C to 40°C
  • Mounting Type: Chassis Mount
  • Termination Style: Threaded Post
  • Approvals: CSA, UR, VDE
  • REACH: Affected
