2-1542006-3

Part No 2-1542006-3
Manufacturer TE Connectivity
Catalog Thermal - Heat Sinks
Description HS 21MM ASSY ULTEM CL  /  Heat Sink BGA Aluminum Top Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Fans, Thermal Management>Thermal - Heat Sinks
Mfr TE Connectivity AMP Connectors
Package Box
Type Top Mount
Package Cooled BGA
Attachment Method Clip
Shape Cylindrical
Diameter 1.000" (25.40mm) OD
Fin Height 0.550" (13.97mm)
Material Aluminum
Material Finish Black Anodized
Base Product Number 1542006
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8473.30.5100
Other Names 2266-2-1542006-3,HTS186-U
Standard Package 450
Win Source Part Number 1035749-2-1542006-3
Ultra Librarian 3D Model Ultra Librarian 2-1542006-3 CAD Model

Description

The TE Connectivity AMP Connectors 1035749-2-1542006-3 Heat Sink for thermal management.

  • Category: Fans, Thermal Management
  • Mount Type: top mount
  • MSL Level: 1 (unlimited)
  • HTSUS: 8473.30.5100
  • Fin Height: 0.550" (13.97mm)
  • Shape: cylindrical
  • Outer Diameter: 1.000" (25.40mm) OD
  • Attachment Method: clip
