1981584-1 Real Image 1981584-1 label picture 1981584-1 real image
Same model may have multiple batches, images only for reference.
1981584-1 Real Image 1981584-1 label picture 1981584-1 real image
1981584-1 Real Image 1981584-1 label picture 1981584-1 real image
Same model may have multiple batches, images only for reference.

1981584-1

Part No 1981584-1
Manufacturer TE Connectivity
Catalog USB, DVI, HDMI Connectors
Description MICRO USB RECEPTACLE STANDARD TYPE AB ASSY | CONN RCPT USB2.0 MICRO AB SMD RA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer TE Connectivity AMP Connectors
Packaging Reel
Connector Type USB - micro AB
Number of Contacts 5
Gender Receptacle
Specifications USB 2.0
Mounting Style SMT, Right Angle
Mounting Feature Horizontal
Termination Solder
Features Solder Retention
Temperature Range - Operating -30°C ~ 85°C
Number of Ports 1
Current Rating (Amps) 0.5A, 1A, 1.8A
Voltage - Rated 30V
Mating Cycles 10000
Shielding Unshielded
Contact Finish Gold
Shell/Shielding Material Steel, Stainless
Insulation Color Gray
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 728687-1981584-1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 1981584-1 CAD Model

Description

The TE Connectivity AMP Connectors 728687-1981584-1 is a high-quality USB micro AB connector that is ideal for use in a variety of electronic applications. This connector is designed to provide excellent performance and reliability, making it a great choice for those in need of a reliable connector solution.

  • Popularity: medium
  • Supply and Demand Status: balanced
  • Manufacturer: TE Connectivity AMP Connectors
  • Win Source Part Number: 728687-1981584-1
  • Applications: automotive, industrial, and consumer electronics
