Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Connectors
Estimated Pruduction Lead Time 16 Weeks
Features Connector Header Through Hole, Right Angle 14 position 0.100" (2.54mm)
Manufacturer TE Connectivity
Series AMP-Latch
Package Tube
Operating Temperature Range -65°C ~ 105°C
Mounting Through Hole, Right Angle
Family Name 1761609
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Part Number 1761609-5-ND, A114965, -1761609-5-SI
Quantity per package 20
Popularity High
Supply and Demand Status Balance
Win Source Part Number 905556-1761609-5
Ultra Librarian 3D Model Ultra Librarian 1761609-5 CAD Model

Description

The TE Connectivity 905556-1761609-5 is a high popularity AMP-Latch connector header that is designed for through hole, right angle 14 position 0.100" (2.54mm) applications. Bold the product name (e.g., BAV99S,135 → 905556-1761609-5) and manufacturer (e.g., Nexperia USA Inc. → TE Connectivity).

  • Type: AMP-Latch connector header
  • Mounting: Through hole, right angle
  • Positions: 14
  • Pitch: 0.100" (2.54mm)
  • Family Name: 1761609
  • Quantity per Package: 20
  • Operating Temperature Range: -65°C ~ 105°C
