1-1393204-4 Real Image
Same model may have multiple batches, images only for reference.

1-1393204-4

Part No 1-1393204-4
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPDT 7A 6V / General Purpose Relay SPDT (1 Form C) 6VDC Coil Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr TE Connectivity Potter & Brumfield Relays
Series V23148, SCHRACK
Package Bulk
Mounting Type Through Hole
Coil Voltage 6VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 7 A
Coil Type Latching, Single Coil
Termination Style PC Pin
Must Operate Voltage 14.7 VDC
Must Release Voltage 1.5 VDC
Temperature Range - Operating -25°C ~ 70°C
Contact Material Silver Nickel (AgNi)
Relay Type General Purpose
Coil Resistance 33 Ohms
Base Product Number 1393204
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.49.0080
Other Names V23148-B0010-A101-ND,V23148-B0010-A101
Standard Package 25
Win Source Part Number 989418-1-1393204-4
Ultra Librarian 3D Model Ultra Librarian 1-1393204-4 CAD Model

Description

The TE Connectivity Potter & Brumfield Relays V23148-B0010-A101-ND is a general-purpose power relay that has a contact rating of 7A.

  • Manufacturer: TE Connectivity Potter & Brumfield Relays
  • Type: General-Purpose Power Relay
  • Contact Rating: 7A
  • Relay Type: Single-Coil Latching
  • Coil Voltage: 6VDC
  • Usage: Commonly used in various electronic devices.
