B0530WS Real Image B0530WS Real Image
Same model may have multiple batches, images only for reference.
B0530WS Real Image B0530WS Real Image
B0530WS Real Image B0530WS Real Image
Same model may have multiple batches, images only for reference.

B0530WS

Part No B0530WS
Manufacturer Taiwan Semiconductor
Catalog Diodes, Rectifiers - Single
Description SOD-323F, 30V, 0.2A, SCHOTTKY DI
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 30 V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 360 mV @ 100 mA
Speed Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr 500 µA @ 30 V
Capacitance @ Vr, F 160pF @ 0V, 1MHz
Mounting Type Surface Mount
Package / Case SC-90, SOD-323F
Supplier Device Package SOD-323F
Operating Temperature - Junction -65°C ~ 125°C
Base Product Number B0530
Standard Package 6,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 567760-B0530WS
Ultra Librarian 3D Model Ultra Librarian B0530WS CAD Model

Description

The 567760-B0530WS is a Schottky diode designed for small signal applications with a maximum reverse voltage of 30V.

  • Maximum Reverse Voltage: 30V
  • Average Rectified Current: 200mA
  • Forward Voltage: 360mV @ 100mA
  • Reverse Leakage Current: 500μA @ 30V
  • Capacitance: 160pF @ 0V and 1MHz
  • Operating Temperature Range: -65°C to 125°C
  • Package Type: SC-90, SOD-323F
  • Packaging: Tape and Reel
  • Standard Package: 6,000 pieces

The 567760-B0530WS is an active product from Taiwan Semiconductor and is widely used in the electronics industry.
