Introducing the VND810PTR-E from STMicroelectronics

The VND810PTR-E is a state-of-the-art power management device manufactured by the renowned semiconductor company, STMicroelectronics. This high-side driver is specifically designed to control automotive applications and is part of STMicroelectronics' VIPower M0-7 series. The device is engineered to deliver exceptional performance, robustness, and reliability for a wide range of vehicular subsystems.

Key Features

• Integrated Efficiency: The VND810PTR-E features an embedded Power MOSFET for high-side switching, which allows for direct control of the load with exceptional energy efficiency.
• Advanced Protection: It includes overcurrent, overvoltage, and overtemperature protection, ensuring the safety and longevity of both the device and the system it controls.
• Diagnostic Functions: The device is equipped with diagnostic feedback that communicates the status of the load, the VDS, and any thermal shutdown events, enabling predictive maintenance and system reliability.
• Flexible Use: With a broad voltage range, the VND810PTR-E is versatile enough for a variety of automotive applications, including but not limited to, lights, heaters, and motors.

Technical Specifications

• Load Type: General Purpose
• Output Current: Up to 25 A
• Operating Voltage: 5.5 V to 36 V
• On-State Resistance: 10 mOhm
• Package: PowerSSO-16

The VND810PTR-E's compact PowerSSO-16 package is designed to minimize space on the PCB, making it an ideal solution for space-constrained automotive environments. Its lead-free, halogen-free construction also ensures compliance with current environmental regulations, reflecting STMicroelectronics' commitment to sustainability.

Applications

Thanks to its robust design and versatile features, the VND810PTR-E is perfectly suited for a variety of automotive applications. These include driving resistive, inductive, and capacitive loads such as:

• Car body lighting
• Engine management systems
• Heating and air conditioning blowers
• Window lifters
• Wiper motors

For designers and engineers seeking a reliable and efficient high-side driver solution, the VND810PTR-E from STMicroelectronics offers an unparalleled blend of performance, protection, and diagnostic capabilities.
