STPS2H100A - High Voltage Power Schottky Rectifier

The STPS2H100A is a robust and efficient power Schottky rectifier designed by STMicroelectronics. It is engineered to meet the demanding requirements of high-frequency power electronics systems. This rectifier is a perfect choice for applications requiring a combination of low voltage drop, high junction temperature capability, and a significant reduction in conduction losses.

Featuring a repetitive peak reverse voltage of 100V and an average forward current of 2A, the STPS2H100A is well-suited for switching power supplies, converters, freewheeling diodes, and reverse battery protection. Its high junction temperature tolerance of up to 175°C ensures reliability and stability in high-temperature environments.

The device comes in a DO-15 package, which is a plastic encapsulated package known for its compact size and ease of mounting on a PCB. This package is also characterized by its excellent thermal performance and mechanical ruggedness, making it a suitable choice for various industrial and consumer applications.

The STPS2H100A boasts a low forward voltage drop, typically only 0.82V at 2A, which contributes to its high efficiency. Furthermore, its low reverse leakage current enhances its performance in low-power applications. The fast switching capability of this Schottky rectifier enables it to handle high-frequency operations with minimal losses, thus improving the overall efficiency of the power management system.

Additional features include its avalanche capability, which provides robustness against voltage transients, and its guard ring for enhanced ruggedness and long-term reliability. The STPS2H100A is also compliant with RoHS and Halogen-free directives, making it an environmentally friendly choice for manufacturers concerned with sustainability.

In summary, the STPS2H100A from STMicroelectronics is a high-performance Schottky rectifier that offers a compelling blend of low power loss, high efficiency, thermal resilience, and reliability for a wide range of power management applications.
