The STGIB30M60TS-L is a state-of-the-art insulated gate bipolar transistor (IGBT) module designed and manufactured by STMicroelectronics, a global semiconductor leader. This IGBT module is part of the SLLIMM™-nano series, which stands for Small Low-Loss Intelligent Molded Module, and is specifically engineered to deliver high power and efficiency in a compact package.

Key Features

• High Power Density: The STGIB30M60TS-L boasts a high current rating, making it suitable for applications requiring high power density.
• Low Losses: With its optimized design, this module ensures low conduction and switching losses, which enhances overall system efficiency.
• High Switching Frequency: The device supports high switching frequencies, allowing for smaller and more efficient power supplies.
• Integrated Features: It includes an anti-parallel diode, which simplifies circuit design and reduces component count.
• Robust Package: Encased in a rugged package, the STGIB30M60TS-L is designed to withstand harsh operating conditions and provide reliable performance over time.

Applications

The versatility of the STGIB30M60TS-L makes it an ideal choice for a wide range of applications, including:

• Motor drives for industrial automation
• Power supplies for servers and telecom systems
• Renewable energy systems, such as solar inverters and wind turbines
• Electric vehicle (EV) charging stations
• Uninterruptible power supplies (UPS)

Technical Specifications

The STGIB30M60TS-L module is characterized by the following technical specifications:

• Operating junction temperature: -40°C to +150°C
• Collector-emitter voltage (V<sub>CE): 600V
• Collector current (I<sub>C): 30A at T<sub>C=80°C
• Short-circuit withstand time: 5μs

In conclusion, the STGIB30M60TS-L from STMicroelectronics is a powerful IGBT module designed for efficiency and reliability in high-performance power conversion applications. Its integration of advanced features in a compact form factor makes it a go-to choice for engineers looking to optimize their power systems.
