STCS1PHR - High Power LED Driver from STMicroelectronics

The STCS1PHR is a high efficiency, high power LED driver designed by STMicroelectronics to meet the demands of modern lighting solutions. This device is capable of driving up to 1.5A of LED current with excellent line and load regulation. The STCS1PHR is a versatile component suitable for a wide range of applications, from architectural and street lighting to signal and marker lights.

Key Features:

• Adjustable Output Current: Users can set the output current from 350mA up to 1.5A, providing flexibility for various LED configurations and applications.
• High Efficiency: With an efficiency rate that can reach up to 95%, the STCS1PHR ensures minimal power loss and heat generation, leading to longer LED life and reduced energy costs.
• Thermal Protection: The device includes an over-temperature protection feature that shuts down the current in the event of excessive heat, safeguarding the LEDs and the driver itself.
• Wide Input Voltage Range: It operates over a broad input voltage range from 6V to 48V, accommodating various power supplies and ensuring consistent LED performance.
• PWM and Analog Dimming: The STCS1PHR supports both pulse-width modulation (PWM) and analog dimming, offering precise control over light intensity and enabling energy-saving strategies.

Applications:

• Architectural lighting
• Street lighting
• Signal and marker lights
• Emergency lighting
• General purpose LED lighting

The STCS1PHR is available in a PowerSO-10 package, which is designed to optimize thermal dissipation and reliability. Its compact form factor makes it an excellent choice for space-constrained applications. The device's robust design ensures performance in harsh environments, making it a reliable solution for outdoor and industrial lighting systems. With its combination of features, the STCS1PHR from STMicroelectronics stands out as a high-performance, adaptable solution for a multitude of high-power LED driving needs.
