L3GD20TR

Part No L3GD20TR
Manufacturer STMicroelectronics
Catalog Motion Sensors - Gyroscopes
Description IC MEMS MOTION SENSOR 16-LGA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Type Digital
Axis X (Pitch), Y (Roll), Z (Yaw)
Range °/s ±250, 500, 2000
Sensitivity (LSB/(°/s)) 8.75 to 70
Bandwidth 47.5Hz to 380Hz
Output Type I2C, SPI
Supply Voltage - Operating 2.4 V to 3.6 V
Operating Supply Current 6.1mA
Features Adjustable Bandwidth, Selectable Scale, Sleep Mode, Temperature Sensor
Temperature Range - Operating -40°C to 85°C (TA)
Dimension 16-VFLGA
Win Source Part Number 018245-L3GD20TR
Family Name L3GD20
Introduction Date August 18, 2011
ECCN EAR99
Country of Origin Malta
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian L3GD20TR CAD Model

Description

STMicroelectronics L3GD20TR Gyroscope

The L3GD20TR is a cutting-edge three-axis digital gyroscope from STMicroelectronics, designed to provide high-precision motion sensing in a variety of applications. This MEMS (Micro-Electro-Mechanical Systems) sensor is an essential component for enhancing user experience in the realm of gaming, virtual reality, and for the stabilization features in cameras and smartphones.

Key Features:

  • Three-Axis Angular Rate Sensor: The L3GD20TR can measure rates of rotation around three perpendicular axes (pitch, yaw, and roll), providing comprehensive motion detection.
  • Wide Measuring Range: It offers a selectable full-scale range of ±250, ±500, and ±2000 degrees per second (dps), making it versatile for different use cases.
  • High Sensitivity: With its high resolution, the gyroscope delivers precise measurements, allowing for accurate motion tracking and navigation.
  • Embedded Features: The device includes a FIFO (First In First Out) buffer, a high-pass filter, and an embedded temperature sensor for advanced data processing and output stabilization.
  • I2C/SPI Digital Output Interface: The L3GD20TR supports both I2C and SPI communication, providing flexibility in system design and ensuring easy integration with a broad range of microcontrollers.

Applications:

  • Gaming and Virtual Reality
  • Smartphones and Tablets
  • Camera and Video Stabilization
  • Robotics and Drones
  • Navigation Systems

The L3GD20TR is also known for its robustness and reliability, with a built-in power-down mode and sleep mode for energy efficiency. Its compact LGA-16 (Land Grid Array) package makes it suitable for space-constrained applications. Whether for personal electronics, industrial, or automotive systems, the L3GD20TR from STMicroelectronics stands as a top choice for designers seeking a high-performance gyroscope solution.
