Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer SEP
Win Source Part Number 106328-DB104S-T
Popularity Low
Supply and Demand Status Balance
Family Name DB104S
ECCN EAR99
Country of Origin China
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DB104S-T CAD Model

Description

DB104S-T - Compact Bridge Rectifier

The DB104S-T is a variant of the DB104S with the same robust performance characteristics. It provides effective AC to DC conversion for low-power applications with its high thermal stability and low forward voltage drop.

  • Applications/Projects:
    • Small home appliances
    • DC power supply systems
    • Portable electronic devices
  • Features and Benefits:
    • Thermal stability for improved performance
    • Compact footprint for easy incorporation into small devices
    • Reliable protection against reverse polarity
  • Additional Details:
    • Peak Reverse Voltage: 400V
    • Average Rectified Current: 1A
    • Operating Temperature: -55°C to +150°C
