F1892SD1600

Part No F1892SD1600
Manufacturer Sensata-Crydom
Catalog SCRs - Single - Modules
Description MODULE SCR/DIODE 90A 600VAC / SCR Module 1.6 kV Series Connection - All SCRs Chassis Mount Module
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Thyristors - SCRs - Modules
Mfr Sensata-Crydom
Series F18
Package Bulk
Product Status Not For New Designs
Structure Series Connection - All SCRs
Number of SCRs, Diodes 2 SCRs
Voltage - Off State 1.6 kV
Voltage - Gate Trigger (Vgt) (Max) 3 V
Current - Gate Trigger (Igt) (Max) 150 mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 1950A @ 60Hz
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Chassis Mount
Package / Case Module
MSL Level Not Applicable
ECCN EAR99
HTSUS 8541.30.0080
Standard Package 5
Win Source Part Number 1213189-F1892SD1600
Ultra Librarian 3D Model Ultra Librarian F1892SD1600 CAD Model

Description

The Sensata-Crydom F1892SD1600 is a module type thyristor with a voltage-off state of 1.6 kV and a voltage-gate trigger (Vgt) (Max) of 3 V.

  • Voltage-Off State: 1.6 kV
  • Voltage-Gate Trigger (Vgt) (Max): 3 V
  • Current-Gate Trigger (Igt) (Max): 150 mA
  • Current-Non Rep. Surge 50, 60Hz (Itsm): 1950A @ 60Hz
  • Series Connection: All SCRs structure
  • SCRs and Diodes: 2 SCRs and diodes
